Consew 146RB Single Needle Drop Feed Walking Foot Zigzag Sewing Machine with Table and Servo Motor

In stock

Consew 146RB Single Needle Drop Feed Walking Foot Zigzag Sewing Machine with Table and Servo Motor

Use theConsew 146RB Single Needle Drop Feed Walking Foot Zigzag Sewing Machine with Table and Servo Motor where you have thicker and toucher materials to sew.

  • For sewing medium to heavy weight fabrics that are difficult to feed when sewn.
  • For such materials and products as wet suits, shoes, boots, leather, tarpaulins. Federal Stitch 304


  • Large bobbin and horizontal axis transverse rotary hook
  • Wide zig-zag
  • Upper feed mechanism helps avoid slippage when sewing
  • Reverse stitching
  • Stitches per minute - 2500*
  • Choose your type of zigzag below 1A, 2A & 3A stitches
  • 146RB - Series Stitches

    Stitch Type-1A
    2-step / 1-stitch zig-zag
    Stitch Type-2A
    3-step / 2-stitch zig-zag
    Stitch Type-3A
    4-step / 3-stitch zig-zag


  • Number of Needles:  1 (Single)
  • Feeding Mechanism:  Walking Foot
  • Workspace:  Standard Workspace
  • Standard or Full Function:  Standard Functions
  • Speed, Max (S.P.M.):  2500
  • Clearance Under Presser Foot: 25/64" (10mm)
  • Stitch Length:  5 s.p.i. (5mm)
  • Work Space:  10" (255mm)
  • Needle:  135 x 17
  • Bobbin:  Metal 212O34-312 Pre-wound M
  • Needle Bar Stroke:  1-11/32" (34mm)
  • Bed Size: 7" 18 7/8" (178m x 480mm)
  • Hook:  B79
  • Zig-Zag Stitch Width:  3/8" (9.5mm)


  • They use up to 90% less power than clutch motors
  • They are 1/3 lighter than clutch motors
  • With a flick of the switch you can reverse motor rotation
  • No parts to wear out or adjust.
  • No matter how hard you press the foot pedal configured speed remains the same

Because of Servo motor speed control, most users find the machine is easier to use.

Major Features of the Servo Motor

  • They save up to 70% electricity than other commercail motors
  • Ligher in weight than other commercial motors
  • Adjustable speed control
  • 110v so no special wiring needed versus other 220v motors.  Most households in the US are wired for standard 110 voltage.


This machine is equiped with a SERVO motor operating on standard 110 Volts power

1 Year Warranty

This is a special order item.

We highly recommend having us assemble and test the machine for you.  Ken's will assemble, test and sew off the machine for you.  We repack them for your choice of freight shipping. Please note we now offer Fedex White Glove Sevice.  White glove will bring the item in your house and then take away all packing and pallet for you.  This includes the frieght to your door.  You are very welcome to send us the thread and a sample of material you are sewing and when we assemble we can test it for you.

Disclaimer: Due to the weight and shipping methods used for industrial machines they may experience marring and scratches during shipping. This will not affect the operation of the machine.

More Information
Part Number 146RB
Condition New
